Automated Guided Vehicles

Automated Guided Vehicles

Automated Guided Vehicles

The SEER Robotics Autonomous Pallet Truck realizes efficient and flexible intelligent logistics handling for you with an extremely narrow body and 1.5 tons of strong load. SEER Robotics is the source manufacturer, eliminating the middleman link and supporting bulk procurement, to provide you with a very competitive ex-factory price and faster delivery speed.

Autonomous pallet trucks are mainly used in narrow-aisle storage and transportation, line-side distribution in manufacturing workshops, large-scale logistics centers, and cross-regional long-distance material handling.

Load:
1.5 tons
Speed:
2 meters per second
Endurance:
up to 10 hours

Automated Guided Vehicle Characteristics

The extremely narrow body breaks through the space limitation:
The width of the body is only 932mm, which can easily shuttle through the narrow storage channel, significantly improving the storage density and overall space utilization rate of the warehouse.
Super load to cope with heavy handling:
Under the compact body design, it can still provide a strong rated load of up to 1.5 tons, which is stable and competent for all kinds of heavy industrial material handling requirements.
Panoramic field of view ensures safe operation:
Supports 360-degree super-large scanning field of view, integrates multiple hardware self-checking protections such as obstacle avoidance LiDAR and safe touch edge, and ensures absolute safety of human-computer cooperation.
High-precision wide-angle compatible multi-carrier:
Supports a high-precision wide-angle recognition algorithm, is perfectly compatible with nine-leg pallets, open pallets, and various non-standard material racks, and meets the diversified needs of complex sites.
Super-large map construction realizes cross-regional dispatching:
It supports the construction of super-large area maps of up to 400,000 square meters and easily realizes long-distance transportation of super-large factory areas with a maximum driving speed of 2 meters per second.
Fast charging and power exchange ensure high endurance:
It supports one-hour fast charging and three-minute fast manual power exchange, and the modular dual battery combination provides up to 10 hours of endurance to ensure all-weather operation of the equipment.
Automated Guided Vehicles Specifications
Parameter Name SFL-CBD15 Standard Edition SFL-CBD15-CE International Edition
Navigation Technology Laser LiDAR SLAM Navigation Laser LiDAR SLAM Navigation
Rated Load Capacity 1500 kg 1500 kg
Load Center Distance 600 mm 600 mm
Vehicle Dimensions 1712 × 932 × 1902 mm 1685 × 980 × 1906 mm
Outer Fork Width 550 / 600 / 680 mm 550 / 600 / 680 mm
Min. Turning Radius 1524 mm 1532 mm
Driving Speed (Full Load) 2 m/s 1.4 m/s
Positioning Accuracy ±10 mm ±10 mm
Standard Battery Spec 48V 23Ah Lithium Iron Phosphate (LiFePO4) 48V 46Ah Lithium Iron Phosphate (LiFePO4)
Operating Time 4 – 6 hours 8 – 10 hours
Obstacle Avoidance LiDAR 1 Main LiDAR & 2 Auxiliary LiDARs 1 Main LiDAR & 2 Safety LiDARs

Automated Guided Vehicles
Contrast Point

The SEER Robotics Autonomous Pallet Truck has shown great advantages in similar intelligent pallet handling equipment with its excellent, extremely narrow body design and strong load capacity of 1.5 tons. Its modular dual-battery combination and three-minute rapid power exchange design greatly extend the operation time and provide a solid guarantee for the high-intensity continuous production of the enterprise. Compared with traditional automation equipment, the SEER Robotics system has achieved a significant leap in map construction and visual perception. The super-large mapping capacity of 400,000 square meters and 360-degree panoramic scanning complement each other, enabling it to maintain extremely high operational stability and scheduling flexibility in complex and changeable large-scale storage and narrow channel environments.

Lorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsumLorem ipsum Lorem ipsumLorem ipsum
In view of the low storage density of narrow channels,
SEER Robotics' extremely narrow body design enables equipment to shuttle freely in narrow aisles, greatly improving the space utilization rate of existing warehouses.
Aiming at the difficulty of identifying non-standard carriers:
Through wide-angle and high-precision identification technology, SEER Robotics accurately adapts the nine-leg tray and non-standard material rack to eliminate the disadvantages of picky carriers.
In view of the anxiety dilemma of high-frequency operation power consumption,
SEER Robotics supports one-hour fast charging and fast power exchange, and the combination of two batteries realizes ten-hour battery life, thus completely saying goodbye to downtime waiting.

Automated Guided Vehicle Instructions

Super-large map scanning and accurate map construction:
Start the panoramic scanning function of the equipment and quickly complete the high-precision map construction of the factory area up to 400,000 square meters.
01
Intelligent adaptation and vehicle fork docking:
In the system to select the corresponding tray type, the equipment will automatically open wide-angle identification to achieve all kinds of non-standard vehicle accurate forks.
02
Fast charging and modular fast power exchange:
When the battery is low, the charging pile can be quickly charged for one hour, or the operator can manually complete the module battery replacement within three minutes.
03
Safety protection opening and daily self-inspection:
Hardware self-inspection is automatically executed every day when starting up, obstacle avoidance LiDAR and safety touch edge real-time monitoring during operation and automatic emergency stop in distress.
04

Automated Guided Vehicles for People

Director of Logistics Operations in Large Manufacturing:

Manager responsible for cross-regional material scheduling in large plants. The equipment has a mapping capacity of 400,000 square meters and a high-speed operation of 2 meters per second, which perfectly meets the needs of long-distance and efficient handling.

E-commerce warehousing and third-party logistics managers:

Warehouse managers who face the test of high-density storage and high-frequency warehousing. The extremely narrow body design can adapt to the compact shelf channel and significantly improve the overall space utilization of the warehouse.

Auto parts incoming logistics engineer:

A field engineer who handles a variety of specially shaped material racks and non-standard pallets. Its high-precision wide-angle recognition system can seamlessly dock all kinds of complex vehicles, effectively reducing the cost of standardized transformation.

Multinational supply chain equipment purchasers:

Decision makers who need to unify the deployment of global automation equipment. The products provide CE-certified versions that meet international high standards and meet the safety and compliance requirements of multiple scenarios at home and abroad.

Certificates And Factories

证书大图

As the world’s leading controller manufacturer, SEER Robotics has independent intellectual property rights of SRC series controllers and production lines. It is the real source manufacturer, providing you with highly competitive ex-factory prices and faster delivery speed. Products comply with international standards and have been deployed in many countries and regions around the world. Through standardized communication protocols, the stable operation and technical compatibility of the system in multinational plant projects are ensured.

证书小图

FAQ

Q: What is the maximum load and applicable channel width of this autonomous pallet truck?
Answer: The rated load of the equipment is as high as 1.5 tons, and the narrowest body of the standard version is only 932mm, which is very suitable for flexible shuttle operation in extremely narrow storage channels.
Q: Can it identify those non-standard-size pallets and racks in the factory?
Answer: Yes, the equipment is equipped with a wide-angle and high-precision identification system, which can be easily compatible with nine-leg trays, open trays, and various non-standard storage racks.
Q: If our factory area is large, can this equipment be fully covered?
A: It is absolutely possible. The system supports the construction of super-large maps of up to 400,000 square meters, which can easily meet the long-distance transportation requirements of super-large factories across regions.
Q: How does the battery life of the device perform? Is it convenient to charge and change electricity daily?
Answer: Single battery life is four to six hours; double battery is up to ten hours. Support one-hour fast charging, and the novice can complete the manual modular power change in only three minutes.
Q: How to ensure personnel safety when operating in a complex workshop environment with human-machine collaboration?
Answer: The equipment has a panoramic field of view of 360 degrees and is equipped with multiple protection mechanisms such as LiDAR, anti-collision strips, and distance sensors to ensure absolute safety of on-site operation.
Q: Does this product have the qualification required for export overseas or global deployment?
A: Yes, this series of products provides international versions that meet strict safety standards such as CE and have passed EMC and UN38.3 tests to meet safety compliance requirements in overseas markets.
